Cold Drawn Carbon Steel Seamless Hydraulic Cylinder Honed Tube

Firstly, the products are of high quality.

>The plant covers an area of 4,0000 square feet, 60 advanced equipment and more than 40 skilled workers.

> Our company has passed ISO9001 certification, with a perfect and strict quality control system.

>100%inspection for each product in each processing make our better final quality.



Secondly, the products have competitive prices.

>The annual output exceeds 20,000 tons. We can meet your order requirements.

> The bulk purchase of raw materials allows us to have a good control over prices.



Thirdly, longer warranty period to avoid any risk choose us.



Our products are exported to more than 40 countries and have been highly praised by clients.



Highly appreciated for your early enquiry! We could be your reliable and standing partner!

  • TUBE

  • DOOHARVEST

  • 84129090.90

Availability:
Quantity:

586c65d990ed67dcf5308ed9e75f0fd



Professional manufacturer of honed tube & chrome rod/bar/shaft, founded in 2004, one of biggest manufacturer in China.

We make honed tubes, Honed steel tubing, Hydraulic cylinder tubes, Skived tubes, Bored tubes; Chrome plated piston rods, Chrome bars, Linear shaft, Hollow rods; Cold drawn tubes, Pre-hone tubes, Ready to hone tubes.



1、 Product Description

Honed tube is produced using our “Suitable to Hone” Drawn Over Mandrel (DOM) and Cold Drawn Seamless (CDS).

The honing process involves using abrasive polishing stones and abrasive paper to remove small amounts of material, to produce extremely precise ID dimensions and improved finishes.

u





Item

Honed   Tube

Raw   material

DIN   ST52, SAE1020

Pressure   & Temperature Classification

High   pressure & temperature piping

Inner   Diameter

40mm-320mm

Outer   Diameter

50-400mm

Thickness

5-40mm

Length

7000mm

Straightness

Max   0.5/1000mm

Inside   Surface Roughness (Ra)

0.2-0.4um

Tolerance   INT

DIN2391   H8

2Production Processes

equipment



3Packing

packagea



4Company Show



Factory was established under modern management system and technologies in 2003. It covers an area of 40,000 sq. meters, plant cover 25,000 sq. meters and building area of 30,000 sq. meters. All processing control include cold-drawn, heat treatment, honing, peeling, grinding, polishing. There are 60sets of advanced equipment and 70+ skilled technical workers, annual output over 20,000tons.

factory1



5Why Choice Us



1.Professional, rich experience, reliable.

2.One-stop collection for honed tube, chrome rod, casting cylinder components.

3.Full range of size and material, ready stock goods with fast delivery

4.Customizable, non-standard sizes available

5.Small quantity acceptable

6.Refund or replace if any quality issue.



6FAQ



Q: Delivery time?

A: Usually could be delivery in 30 days, urgent order could be delivery in 15days.



Q: What ’s your main market?

A: We mainly export to Middle East, South Africa and South Eastern Asia. And these two years our products enter to South America too.



Q: Are you a factory?

A: Yes, we are.



Q: Guarantee period?

A: One-year after manufactured, reject items will be resupply or refund.
